Pinch valve Series PI03 Store
  1. Products
  2. Armatures
  3. Valves, butterfly valves and gate valves - automatically operated
  4. Pinch valves - pneumatically operated
  5. Pinch valve Series PI03
  6. PI03-34-NZS-52-ABS30-C001-03-C002-31-6
PI03-34-NZS-52-ABS30-C001-03-C002-31-6
PI03-34-NZS-52-ABS30-C001-22-C002-31-LVCV20-1
PI03-34-NZS-52-ABS30-C001-22-C002-31-LVCV20-1
4.009,00 zł
4.009,00 zł
PI03-34-NZS-52-ABS30-C001-03-C002-31-LV-2
PI03-34-NZS-52-ABS30-C001-03-C002-31-LV-2
3.969,50 zł
3.969,50 zł

PI03-34-NZS-52-ABS30-C001-03-C002-31-6

PI03-34-NZS-52
Pinch valve Series PI03; NC; Connection parts 1.4435; Tube NBR food-safe; Medium temperature -20...+80°C; RP 3/4"; DN 20mm; Pressure range 0-3bar; Control pressure 4,4-10bar; Diameter Actuator 50mm
ABS30
Mounted pilot valve Series ABS; Silencer; Suitable for Pneumatically operated seat valves Series SE, Pinch valves Series PI03, Series PI04; 3/2-Wegemagnetventil (PS125-18-C); Standard coil C001; Connector size 22mm; Actuator 50 mm
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818079
Country of origin: Germany
Weight: 2.384 Kg
Short Itemnumber:PI0334NZS52ABS30C00103C002316
