Spiral hose P0T001

Spiral hose P0T001

STASTO Combination
Consists of:
10m Fabric hose for compressed air Series CA; High flexible; Oil resistant; Material Soft-PVC; Operating pressure at 23°C 16bar; Multiplier for operating pressure 60°C = 0,5; Temperature range -20...60°C; Colour Black; Outside diameter 14,5mm; Inside diameter 9mm
Coupling And Coupling plug DN 7,2; Nickel plated brass; Seal NBR

Intrastat No.: 39173200
Country of origin: France
Weight: 1.33 Kg
Short Itemnumber: P0T001
https://www.stasto.pl/web/image/product.template/177716/image_1920?unique=ba7a68c

STASTO Combination
consists of:
10m fabric hose for compressed air series CA; high flexible; oil resistant; material soft-PVC; operating pressure at 23°C 16bar; multiplier for operating pressure 60°C = 0,5; temperature range -20...60°C; colour black; outside diameter 14,5mm; inside diameter 9mm
coupling and coupling plug DN 7,2; nickel plated brass; seal NBR

356,40 zł 356.4 PLN 356,40 zł

cena na zapytanie

excl. tax
  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element
  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Brand STASTO
Brand STASTO
Fabric hose for compressed air CA-14,5/9-BK-1-YA
CA-14,5/9-BK-1-YA x 10.0 m
Fabric hose for compressed air CA-14,5/9-BK-1-YA
Fabric hose for compressed air Series CA; High flexible; Oil resistant; Material Soft-PVC; Operating pressure at 23°C 16bar; Multiplier for operating pressure 60°C = 0,5; Temperature range -20...60°C; Colour Black; Outside diameter 14,5mm; Inside diameter 9mm
Coupling DN 7,2 C0C72-H09-N
C0C72-H09-N x 1.0 Pcs
Coupling DN 7,2 C0C72-H09-N
Coupling DN 7,2; Hose nozzle; Nickel plated brass; Seal NBR; Pressure -0,87...35bar; Temperature Max. 100°C; Hose nozzle 9mm
Coupling plug DN 7,2 C0P72-H09-N
C0P72-H09-N x 1.0 Pcs
Coupling plug DN 7,2 C0P72-H09-N
Coupling plug DN 7,2; Hose nozzle; Nickel plated brass; Pressure -0,87...35bar; Temperature Max. 100°C; Hose nozzle 9mm
Hose clip 158B
158B x 2.0 Pcs
Hose clip 158B
Hose clip Series 158; Screw flight; Chromium steel 1.4016; Bandwidth 9mm; Clamping range 10-16mm
