Bourdon tube manometer MA029-63NR-25-D
Bourdon tube manometer Series MA029-R; Body Stainless steel 1.4301; Measuring unit 1.4404; Front glass Flat instrument glass; Ambient temperature -40...+60°C; Medium temperature Max. +200°C; Connection Rear; Diameter 63mm; Indicating range 0...25; Unit bar/psi; Connection 1/4"NPT; Class 1,6
Intrastat No.: 90262040
Country of origin: Austria
Weight: 100.0 Kg
Short Itemnumber: MA02963NR25D
Country of origin: Austria
Weight: 100.0 Kg
Short Itemnumber: MA02963NR25D
bourdon tube manometer series MA029-R; body stainless steel AISI 304; measuring unit AISI 316L; front glass flat instrument glass; ambient temperature -40...+60°C; medium temperature max. +200°C; connection rear; diameter 63mm; indicating range 0...25; unit bar/psi; connection 1/4"NPT; class 1,6
| dimension | |
|---|---|
| Diameter | 63 mm |
| Connection | 1/4" NPT |
| characteristics | |
| Indicating range | 0...25 |
| Unit | bar/psi |
| Class | 1,6 |
No spare parts are available for this product.
