Bourdon tube manometer Series MA029-B; Body Stainless steel 1.4301; Measuring unit 1.4404; Front glass Flat instrument glass; Ambient temperature -40...+60°C; Medium temperature Max. +200°C; Connection Below; Diameter 63mm; Indicating range 0...250; Unit bar; Connection 1/4"; Class 1,6; Mehrschicht-Sicherheitsglas
Country of origin: Austria
Weight: 0.15 Kg
Short Itemnumber: MA02963B250
bourdon tube manometer series MA029-B; body stainless steel AISI 304; measuring unit AISI 316L; front glass flat instrument glass; ambient temperature -40...+60°C; medium temperature max. +200°C; connection below; diameter 63mm; indicating range 0...250; unit bar; connection 1/4"; class 1,6; Mehrschicht-Sicherheitsglas
Technical specifications
| Connection | 1/4" |
|---|---|
| Diameter | 63 mm |
| Indicating range | 0...250 |
| Unit | bar |
| Connection | 1/4" |
| Diameter | 63 mm |
| Indicating range | 0...250 |
| Unit | bar |
| Class | 1,6 |
MA029-63B-250
Documents
Czech / Čeština
Data Sheets
1-
PDF
Datový list · Manometr s trubkovou pružinou série MA029-B · CS
Data sheet 352 KB Updated 13/06/2026
German / Deutsch
Data Sheets
1-
PDF
Datenblatt · Rohrfedermanometer Serie MA029-B · DE
Data sheet 351 KB Updated 13/06/2026
English
Data Sheets
1-
PDF
Data sheet · Bourdon tube manometer Series MA029-B · EN
Data sheet 350 KB Updated 13/06/2026
Hungarian / Magyar
Data Sheets
1-
PDF
Adatlap · bourdoncsöves nyomásmérő sorozat MA029-B · HU
Data sheet 352 KB Updated 13/06/2026
Polish / Język polski
Data Sheets
1-
PDF
Arkusz danych · manometr z rurką Bourdona Seria MA029-B · PL
Data sheet 353 KB Updated 13/06/2026
Slovenian / slovenščina
Data Sheets
1-
PDF
Podatkovni list · Manometer z Bourdonovo cevjo serija MA029-B · SL
Data sheet 351 KB Updated 13/06/2026
Serbian (Latin) / srpski
Data Sheets
1-
PDF
Tehnički list · Burdonov manometar, konstrukcija: opružna cev serije MA029-B · SRLATIN
Data sheet 351 KB Updated 13/06/2026
