KN0204

KN0204

STASTO Combination
Fully assembled and tested
Incl. Cylinder NWT-80-320;
Incl. E52W1SM18 5/2-way valve Monostable, G-80/100 Rod clevis; Voltage 24VDC; Rear Mounted; Extanded without current

Intrastat No.: 84123100
Country of origin: Italy
Weight: 5.542 Kg
Short Itemnumber: KN0204
https://www.stasto.pl/web/image/product.template/179417/image_1920?unique=351c77c

STASTO Combination
fully assembled and tested
incl. cylinder NWT-80-320;
incl. E52W1SM18 5/2-way valve monostable, G-80/100 rod clevis; voltage 24VDC; rear mounted; extanded without current

2.020,50 zł 2020.5 PLN 2.020,50 zł

cena na zapytanie

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Profile magnetic cylinder PC60-80-320
PC60-80-320 x 1.0
Profile magnetic cylinder PC60-80-320
profile magnetic cylinder series PC60; according to ISO 15552, VDMA; double acting; pressure range 0,5...10bar; adjustable cushions; diameter 80mm; stroke 320mm; piston rod thread M20x1,5; connection 3/8"; push force at 6 bar 3014N
Add to Cart
5/2-way valve E52W1SM18
E52W1SM18 x 1.0
5/2-way valve E52W1SM18
5/2-way valve Series E5.; Pilot-operated; Actuation Electrical/spring; Standard coil C001; Connector size 22mm; Connection 1/8"; Nominal diameter 6mm; Pressure range 3,2-10bar; Flow rate 650Nl/min
Add to Cart
C002-31-LV-2
C002-31-LV-2 x 1.0
C002-31-LV-2
Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC
Add to Cart
Plastic hose PA-8/6-BK-1
PA-8/6-BK-1 x 0.5
Plastic hose PA-8/6-BK-1
Plastic hose Series PA; Material Polyamide; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; Vacuum -0,87bar; Temperature range -60...130°C; Outside diameter 8mm; Inside diameter 6mm; Operating pressure at 23°C 20bar; Colour schwarz
