HEI002

HEI002

STASTO Combination
Fully assembled and tested
Consists of:
1 x MBA01-38; Manual shut-off valve; 3/2-way; Lockable; Connection 3/8"; Flow at 6,3bar/Δp=1bar 1500Nl/min; Max. inlet pressure 12,5bar;
1 x FR-38-20-08-R-PE-SS; Filter regulator Incl. Manometer; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Max. inlet pressure 12,5bar
1 x SV-38-E1S; Solenoid valve; 3/2-way; Inlet pressure 3...10bar; 24VDC; Connector size 22mm; Actuation Electrical/spring; Incl. Coil And Connector;
2 x Silencer

Intrastat No.: 84811005
Country of origin: Italy
Weight: 1.261 Kg
Short Itemnumber: HEI002
https://www.stasto.pl/web/image/product.template/194349/image_1920?unique=351c77c

STASTO Combination
fully assembled and tested
consists of:
1 x MBA01-38; manual shut-off valve; 3/2-way; lockable; connection 3/8"; flow at 6,3bar/Δp=1bar 1500Nl/min; max. inlet pressure 12,5bar;
1 x FR-38-20-08-R-PE-SS; filter regulator incl. manometer; relieving; drain valve semi-automatic; pressure range 0,5...8bar; filter element 20µm; plastic bowl with protection cage; max. inlet pressure 12,5bar
1 x SV-38-E1S; solenoid valve; 3/2-way; inlet pressure 3...10bar; 24VDC; connector size 22mm; actuation electrical/spring; incl. coil and connector;
2 x silencer

1.655,30 zł 1655.3 PLN 1.655,30 zł

cena na zapytanie

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Filter regulator FR-38-20-08-R-PE-SS
FR-38-20-08-R-PE-SS x 1.0
Filter regulator FR-38-20-08-R-PE-SS
Filter regulator Series FR01/FR; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Connection 3/8"; Flow at 6,3bar/Δp=1bar 2100Nl/min; Max. inlet pressure 12,5bar
Add to Cart
Solenoid valve SV-38-E1S
SV-38-E1S x 1.0
Solenoid valve SV-38-E1S
Solenoid valve Series SV; 3/2-way; Inlet pressure 3...10bar; Type of coil C001; Connector size 22mm; Actuation Electrical/spring; Connection 3/8"; Flow at 6,3bar/Δp=1bar 1500Nl/min; Exhaust port 1/4"
