HAU003

HAU003

STASTO Combination
fully assembled and tested
consists of:
1x RE03-38-0,5/16-MA; pressure regulator series Modul RE03; relieving; inlet pressure max. 16bar; connection 3/8"; flow at 6bar/Δp=1bar 1500Nl/min; pressure range 0,5-16bar;
1x FI03-14H; filter series Modul FI03; drain valve semi-automatic; inlet pressure max. 16bar; plastic bowl; filter element 5µm; connection 3/8"; flow at 6bar/Δp=1bar 2100Nl/min

Intrastat No.: 84811099
Country of origin: Germany
Weight: 1.12 Kg
Short Itemnumber: HAU003
https://www.stasto.pl/web/image/product.template/230935/image_1920?unique=351c77c

STASTO Combination
fully assembled and tested
consists of:
1x RE03-38-0,5/16-MA; pressure regulator series Modul RE03; relieving; inlet pressure max. 16bar; connection 3/8"; flow at 6bar/Δp=1bar 1500Nl/min; pressure range 0,5-16bar;
1x FI03-14H; filter series Modul FI03; drain valve semi-automatic; inlet pressure max. 16bar; plastic bowl; filter element 5µm; connection 3/8"; flow at 6bar/Δp=1bar 2100Nl/min

666,60 zł 666.6 PLN 666,60 zł

cena na zapytanie

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Filter FI03-12
FI03-12 x 1.0
Filter FI03-12
Filter Series Modul FI03; Drain valve Semi-automatic; Inlet pressure Max. 16bar; Plastic bowl; Filter element 5µm; Connection 1/2"; Flow at 6bar/Δp=1bar 4000Nl/min
