Valves, butterfly valves and gate valves - manually operated

List prices PL
BUWV-080-DSV-B
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner FKM; Medium temperature -10...+200°C; DN 80mm; Length 46mm; Pressure range 0…25bar; Flange PN25
PS-GL1NE2D2W-2-150-2EM-01
Packing for GL1NE2D2W-2-150-2EM-01, Cotton greased
PS-GL1NE2D2W-2-125-2EM-01
Packing for GL1NE2D2W-2-125-2EM-01, Cotton greased
BUW6-300-DPE-L-EB0X47
Butterfly valve with hand lever; ATEX II 2 G/D Ex h; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 300mm; Length 78mm; Disc Zinc plated ductile iron EN-GJS-400-15
incl. pre-assembled limit switch box; IP67; 2 Micro switches; Switching capacity 3A/250VAC-3A/24VDC; Contact material Silver-nickel; Material of case Aluminum; With visual position indicator On/off
BUW6-250-DPE-L-EB0X47
Butterfly valve with hand lever; ATEX II 2 G/D Ex h; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 250mm; Length 68mm; Disc Zinc plated ductile iron EN-GJS-400-15
incl. pre-assembled limit switch box; IP67; 2 Micro switches; Switching capacity 3A/250VAC-3A/24VDC; Contact material Silver-nickel; Material of case Aluminum; With visual position indicator On/off
BUW6-050-DSE-X-A
Butterfly valve with hand lever Series BUW6-DSE-X; ATEX II 2 G/D Ex h X; Hand lever Stainless steel; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 50mm; Length 43mm
BUW6-080-DSE-X-A
Butterfly valve with hand lever Series BUW6-DSE-X; ATEX II 2 G/D Ex h X; Hand lever Stainless steel; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 80mm; Length 46mm
BUW6-150-DSE-X-A
Butterfly valve with hand lever Series BUW6-DSE-X; ATEX II 2 G/D Ex h X; Hand lever Stainless steel; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 150mm; Length 56mm
BUW6-200-DPE-L-EB0X47
Butterfly valve with hand lever; ATEX II 2 G/D Ex h; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 200mm; Length 60mm; Disc Zinc plated ductile iron EN-GJS-400-15
incl. pre-assembled limit switch box; IP67; 2 Micro switches; Switching capacity 3A/250VAC-3A/24VDC; Contact material Silver-nickel; Material of case Aluminum; With visual position indicator On/off
BUW6-080-DSVS-L
Butterfly valve with hand lever Series BUW6-DSV-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4401; Liner FKM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+200°C; Pressure range 0...16bar; DN 80mm; Length 46mm
BUW6-200-DSVS-L
Butterfly valve with hand lever Series BUW6-DSV-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4401; Liner FKM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+200°C; Pressure range 0...16bar; DN 200mm; Length 60mm
BUW6-300-DSVS-L
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4401; Liner FKM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+200°C; Pressure range 0...16bar; DN 300mm; Length 78mm
GL182-25-W
Globe valve; PN100; Body steel; Seat, poppet, stem stainless steel 1.4021; Handwheel steel; Packing gland Graphite; Back seal; Metal sealing; Rising stem; Medium temperature -29…+400°C; DN 25mm; Length 210mm; Pressure range 0-100bar
BUA5-200-DSED-B
Butterfly valve with bare shaft Series BUA-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4021; Liner EPDM; Medium temperature -20°C...+130°C; Nominal flange pressure PN6/10/16/ANSI150; Pressure range 0...16bar; DN 200mm; Length 60mm
BUA5-250-DSED-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4021; Liner EPDM; Medium temperature -20°C...+130°C; Nominal flange pressure PN6/10/16/ANSI150; Pressure range 0...16bar; DN 250mm; Length 68mm
BUA5-300-DSND-B
Butterfly valve with bare shaft Series BUA-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4021; Liner NBR; Medium temperature -10°C...+90°C; Nominal flange pressure PN6/10/16/ANSI150; Pressure range 0...16bar; DN 300mm; Length 78mm
BUA5-350-DSND-B
Butterfly valve with bare shaft Series BUA-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4021; Liner NBR; Medium temperature -10°C...+90°C; Nominal flange pressure PN6/10/16/ANSI150; Pressure range 0...16bar; DN 350mm; Length 78mm
BUA5-400-DSND-B
Butterfly valve with bare shaft Series BUA-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4021; Liner NBR; Medium temperature -10°C...+90°C; Nominal flange pressure PN6/10/16/ANSI150; Pressure range 0...16bar; DN 400mm; Length 102mm
Butterfly valve with bare shaft;Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner FKM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10…+200°C; Pressure range 0...6bar; DN 600mm; Length 154mm
GB-BA089-150/200
Gear box; Suitable for series 76 /BA089- DN150/200; Material Cast iron
