Valves, butterfly valves and gate valves - manually operated

List prices PL
BULC-400-DPNZ-B
butterfly valve with bare shaft series BULC-DPNZ-B; lug type; length according to EN558−1R20; body ductile iron EN-GJS-400-15 epoxy coated; shaft AISI 430; liner NBR; medium temperature -10...+100°C; DN 400mm; length 102mm; disc zinc plated ductile iron EN-GJS-400-15; pressure range 0…10bar; flange PN10
BULC-400-DSNZ-B
butterfly valve with bare shaft seriesBULC-DSNZ-B; lug type; length according to EN558−1R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+100°C; DN 400mm; length 102mm; pressure range 0…10bar; flange PN10
BULC-450-DPNZ-B
Butterfly valve with bare shaft Series BULC-DPNZ-B; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Shaft 1.4016; Liner NBR; Medium temperature -10...+100°C; DN 450mm; Length 114mm; Disc Zinc plated ductile iron EN-GJS-400-15; Pressure range 0…10bar; Flange PN10
BUW6-450-CPVZ-B
butterfly valve with bare shaft series BUW6-CPVZ-B; wafer type; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; shaft AISI 430; liner FKM; medium temperature -10...+200°C; DN 450mm; length 114mm; disc zinc plated ductile iron EN-GJS-400-15; pressure range 0…10bar; flange PN10
BUW6-450-CSVZ-B
butterfly valve with bare shaft series BUW6-CSVZ-B; wafer type; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; disc AISI 316; shaft AISI 430; liner FKM; medium temperature -10...+200°C; DN 450mm; length 114mm; pressure range 0…10bar; flange PN10
BUW6-500-CPVZ-B
butterfly valve with bare shaft series BUW6-CPVZ-B; wafer type; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; shaft AISI 430; liner FKM; medium temperature -10...+200°C; DN 500mm; length 127mm; disc zinc plated ductile iron EN-GJS-400-15; pressure range 0…10bar; flange PN10
BUW6-500-CSVZ-B
butterfly valve with bare shaft series BUW6-CSVZ-B; wafer type; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; disc AISI 316; shaft AISI 430; liner FKM; medium temperature -10...+200°C; DN 500mm; length 127mm; pressure range 0…10bar; flange PN10
BUW6-350-CPDZ-B
butterfly valve with bare shaft series BUW6-CPDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 350mm; length 78mm; disc zinc plated ductile iron EN-GJS-400-15; pressure range 0…10bar; flange PN10
BUW6-350-CSDZ-B
butterfly valve with bare shaft series BUW6-CSDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 350mm; length 78mm; pressure range 0…10bar; flange PN10
BUW6-400-CPDZ-B
butterfly valve with bare shaft series BUW6-CPDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 400mm; length 102mm; disc zinc plated ductile iron EN-GJS-400-15; pressure range 0…10bar; flange PN10
BUW6-400-CSDZ-B
butterfly valve with bare shaft seriesBUW6-CSDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 400mm; length 102mm; pressure range 0…10bar; flange PN10
BUW6-450-CPDZ-B
butterfly valve with bare shaft series BUW6-CPDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 450mm; length 114mm; disc zinc plated ductile iron EN-GJS-400-15; pressure range 0…10bar; flange PN10
BUW6-450-CSDZ-B
butterfly valve with bare shaft series BUW6-CSDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 450mm; length 114mm; pressure range 0…10bar; flange PN10
BUW6-500-CPDZ-B
butterfly valve with bare shaft series BUW6-CPDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 500mm; length 127mm; disc zinc plated ductile iron EN-GJS-400-15; pressure range 0…10bar; flange PN10
BUW6-500-CSDZ-B
butterfly valve with bare shaft series BUW6-CSDZ-B; wafer type; DVGW-gas-approved; length according to EN558−1R20; body made of carbon steel A216-WCB epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+60°C; DN 500mm; length 127mm; pressure range 0…10bar; flange PN10
BULY-100-DNE-B-01
butterfly valve with bare shaft series BUL-B-01; lug type; length according to EN558−1 R20; body ductile iron EN-GJS-400-15 epoxy coated; disc aluminium-bronze; shaft AISI 430; liner EPDM; medium temperature -10...+130°C; DN 100mm; length 52mm; pressure range 0…16bar; nominal flange pressure ANSI150; flange thread UNC
C3J-BULY-100-DNE-02
inspection certificate EN-10204-3.1; for material, pressure and tightness
C3J-BULY-100-DNE-03
inspection certificate EN-10204-3.1; for material, pressure and tightness
CPA-BULY-100-DNE-03
painting certificate
BULY-100-DNE-B-3C02
Butterfly valve with bare shaft Series BUL-B-3C02; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5009 C5-High According to EN-ISO 12944; Disc Aluminium-bronze; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Stainless steel nameplate; Stainless steel screws; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
