Valves, butterfly valves and gate valves - manually operated

List prices PL
BUW4-080-SSTS-B-01
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body 1.4408; Disc And Shaft 1.4408; Liner PTFE/silicone; Nominal flange pressure PN10/16/ANSI150; Medium temperature -55...+190°C; Pressure range 0...10bar; DN 80mm; Length 46mm; Incl. Notch impact test For Body
BULG-100-SSES-L
Butterfly valve with hand lever Series BULG-SSES-L; Lug type; Length According to EN558−1R20; Body, Disc And Shaft 1.4408; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure PN10/16
C3J-BULG-100-SSES
Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULG-100-SSNS-B-3C
Butterfly valve with bare shaft Series BULG-SSNS-B-3C; Lug type; Length According to EN558−1R20; Body, Disc And Shaft 1.4408; Liner NBR; Medium temperature -10...+100°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure PN10/16; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BULG-100-SSNS
Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULG-100-SSVS-B-3C
Butterfly valve with bare shaft Series BULG-SSVS-B-3C; Lug type; Length According to EN558−1R20; Body; Disc And Shaft 1.4408; Liner FKM; Medium temperature -10...+200°C; DN 100mm; Length 52mm; Pressure range 0...16bar; Nominal flange pressure PN10/16; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
C3J-BULG-100-SSVS
Inspection certificate EN-10204-3.1; For material, pressure and tightness
GL125-150-W-C
Globe valve; PN25; With control cone;; Body Ductile iron EN-GJS-400-15; Seat, Cone, Stem Stainless steel 1.4021; Handwheel Steel; Bellow 1.4541; Rising stem; Medium temperature -10...+350°C; Pressure range 0...25bar; DN 150mm; Length 480mm
BULG-100-SSES-L-3C
Butterfly valve with hand lever Series BULG-SSES-L-3C; Lug type; Length According to EN558−1R20; Body, Disc And Shaft 1.4408; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Flange PN10/16; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BULG-100-SSES-X-3C
Butterfly valve with hand lever; Lug type; Length According to EN558−1R20; Body, Disc And Shaft 1.4408; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure PN10/16; Hand lever Stainless steel; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BULY-150-DNE-B
Butterfly valve with bare shaft Series BULY-DNE-B; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Aluminium-bronze; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; Nominal flange pressure ANSI150; Pressure range 0...16bar; DN 150mm; Length 56mm
BULY-150-DNE-B-01
Butterfly valve with bare shaft Series BULY-DNE-B-01; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Aluminium-bronze; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; Nominal flange pressure ANSI150; Flange thread UNC; Pressure range 0...16bar; DN 150mm; Length 56mm
GA-A1N2I2-5-125
Gate for A1N2I2-5-125; Stainless steel AISI 316; DN125mm
BULY-150-DSES-B-01
Butterfly valve with bare shaft Series BULY-DSES-B-01; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4401; Liner EPDM; Medium temperature -10...+130°C; DN 150mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-150-DNES-B-01
Butterfly valve with bare shaft Series BULY-DNES-B-01; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Aluminium-bronze; Shaft 1.4401; Liner EPDM; Medium temperature -10...+130°C; Nominal flange pressure ANSI150; Flange thread UNC; Pressure range 0...16bar; DN 150mm; Length 56mm
BULY-150-DNES-B-3C01
Butterfly valve with bare shaft Series BULY-DNES-B-3C01; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Aluminium-bronze; Shaft 1.4401; Liner EPDM; Medium temperature -10...+130°C; Nominal flange pressure ANSI150; Flange thread UNC; Pressure range 0...16bar; DN 150mm; Length 56mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BULY-150-DNES-01
Inspection certificate EN-10204-3.1; For material, pressure and tightness
PS-D3N2A4-5-125
Packing for D3N2A4-5-125
BULY-150-DNES-B-3H02
Butterfly valve with bare shaft Series BULY-DNES-B-3H02; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated C4H According to EN-ISO 12944; Disc Aluminium-bronze; Shaft 1.4401; Liner EPDM; Medium temperature -10...+130°C; Nominal flange pressure ANSI150; Flange thread UNC; Pressure range 0...16bar; DN 150mm; Length 56mm; Incl. Inspection certificate API 598 For pressure and tightness; Incl. Inspection certificate EN-10204-3.1 For material
CAE-BULY-150-DNES-02
Inspection certificate API 598 For pressure and tightness; Inspection certificate EN-10204-3.1 For material
