Valves, butterfly valves and gate valves - manually operated

List prices PL
BUW9-150-SSIS-L-F
butterfly valve with hand lever; wafer type; length according to EN558−1R20; housing and disc AISI 316; shaft AISI 630; seat Inconel 625; nominal flange pressure PN10/16/25/ANSI150; medium temperature -10...+500°C; pressure range 0...20bar; DN 150mm; length 56mm
BUW9-200-CSRQ-B-A3E01
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat RTFE; Medium temperature -29...+230°C; Pressure range 0...25bar; ATEX II 2G/D Ex H X; DN 200mm; Length 61mm; Nominal flange pressure PN10/16/25/ANSI150; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness And Notch impact test
BUW9-350-CHRS-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body Steel Epoxy coated; Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 350mm; Length 92mm
BUW9-350-CHRS-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Steel Epoxy coated; Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 350mm; Length 92mm
BUW9-350-HHRS-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body, Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 350mm; Length 92mm
BUW9-350-HHRS-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body, Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 350mm; Length 92mm
BUW9-350-SSRS-B-A
butterfly valve with bare shaft; wafer type; length according to EN558−1R20; housing steel epoxy coated; disc AISI 316; shaft AISI 630; seat RTFE; medium temperature -10...+230°C; pressure range 0...25bar; DN 350mm; length 92mm; nominal flange pressure PN10/16/25/ANSI150
BUW9-400-CHRS-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body Steel Epoxy coated; Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 400mm; Length 102mm
BUW9-400-CHRS-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Steel Epoxy coated; Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 400mm; Length 102mm
BUW9-400-HHRS-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body, Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -60...+230°C; Pressure range 0...25bar; DN 400mm; Length 102mm
BUW9-400-HHRS-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body, Disc Hastelloy, Shaft 1.4542; Seat RTFE; Nominal flange pressure PN10/16/25/ANSI150; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 400mm; Length 102mm
BUWA-300-CSIQ-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat Inconel 625; Medium temperature -10...+425°C; Pressure range 0...16bar; DN 300mm; Length 78mm; Nominal flange pressure PN16
BUWA-400-CTQD-G
Butterfly valve with manual gear box Triple eccentric; Wafer type; Length According to ISO 5752-20; Body Carbon steel; Disc 1.4021 Nitrided, Shaft 1.4021; Seat 1.4401+Graphite; Nominal flange pressure PN16; Medium temperature -30…+425°C; Pressure range 0...16bar; DN 400mm; Length 103mm; Tightness According to API 598, EN ISO 12266-1 A (For liquids)
BUWC-1000-DSE-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10; Medium temperature -10...+120°C; Pressure range 0...10bar; DN 1000mm; Length 216mm
BUWC-600-DSE-G
Butterfly valve with gear box; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 600mm; Length 154mm; Pressure range 0…10bar; Flange PN10
BUWC-600-DSV-B
Butterfly valve with bare shaft; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner FKM; Nominal flange pressure PN10; Medium temperature -10...+200°C; Pressure range 0...10bar; DN 600mm; Length 154mm
BUWC-700-DPE-D22-01
Butterfly valve with pneumatic actuator; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 700mm; Length 165mm; Disc Zinc plated ductile iron EN-GJS-400-15; Pressure range 0…10bar; Flange PN10; With mounted digital positioner, 4-20mA
BUWC-700-DPE-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Ductile iron EN-GJS-400-15, Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10; Medium temperature -10...+130°C; Pressure range 0...10bar; DN 700mm; Length 165mm
BUWC-700-DSE-D22-01
Butterfly valve with pneumatic actuator; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 700mm; Length 165mm; Disc 1.4408; Pressure range 0…10bar; Flange PN10; With mounted digital positioner, 4-20mA
BUWC-800-DPE-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Ductile iron EN-GJS-400-15, Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10; Medium temperature -10...+130°C; Pressure range 0...10bar; DN 800mm; Length 190mm
