Valves, butterfly valves and gate valves - manually operated

Butterfly valve with manual gear box; Lug type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat Inconel 625; Medium temperature -10...+425°C; Pressure range 0...25bar; DN 125mm; Length 56mm; Nominal flange pressure PN25

BU149L300-S-E-PA

Butterfly valve with manual gear box; Lug type; Length According to EN558−1R20; Body, Disc And Shaft 1.4408; Liner EPDM; Medium temperature -10...+130°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; DN 300mm; Length 78mm; Pressure range 0...16bar; Flange PN16

A1V2I2-5-350-PM

Knife gate valve with handwheel; Wafer type; Rising stem; Body 1.4408; Gate 1.4401; Soft sealed EPDM; Packing PTFE-Synthetic/EPDM Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 350mm; Length 96mm; Pressure range 0-5bar; Prepared for 2 mechanical switches MSU01

LIBU-500-S

Liner; Suitable for Butterfly valves Series BUW6, BUW2, BUW4, BULG And BULC; Material Silicone; Nominal diameter 500mm

BULC-450-DPD-G

Butterfly valve with manual gear box; Lug type; DVGW-gas-approved; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Ductile iron EN-GJS-400-15 Zinc plated; Shaft 1.4016; Liner NBR ; Nominal flange pressure PN10; Medium temperature -10...+60°C; Pressure range 0...10bar; DN 450mm; Length 114mm

GL146-125-W-01

Globe valve; PN40; With pressure balanced seat; Bellow; Body Steel; Seat, Cone, Stem Stainless steel 1.4021; Handwheel Steel; Packing gland Graphite; Back seal; Metal sealing; Non rising stem; Medium temperature -10...+400°C; DN 150mm; Length 480mm; Pressure range 0…40bar

GL146-150-W

Globe valve; PN40; Bellow; Body Steel; Seat, Cone, Stem Stainless steel 1.4021; Handwheel Steel; Packing gland Graphite; Back seal; Metal sealing; Non rising stem; Medium temperature -10...+400°C; DN 150mm; Length 480mm; Pressure range 0…21bar

BULA-150-CSRS-S12-A3C

Butterfly valve with pneumatic actuator; Lug type; Length According to EN558−1 R20; Body Steel; Disc 1.4408; Shaft 1.4542; Seat RTFE; Nominal flange pressure PN16; Medium temperature -10...+230°C; Pressure range 0...16bar; ATEX II 2G/D c TX; DN 150mm; Length 56mm; Single acting actuator PAS1805; Control pressure 5,5...8bar; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; Certificate TR CU; With valve pass And Verify Safety; Notch impact test

BULA-250-CSIS-B

Butterfly valve with bare shaft; Lug type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat Inconel 625; Medium temperature -10...+425°C; Pressure range 0...16bar; DN 250mm; Length 69mm; Nominal flange pressure PN16

BUW3A-300-CSRS-B-A

Butterfly valve with bare shaft; Wafer type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat RTFE; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 300mm; Length 78mm; Nominal flange pressure PN10

BULZ-250-DZTS-B

Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4542 PTFE-coated; Shaft 1.4408; Liner PTFE/silicone; Nominal flange pressure PN16; Medium temperature -10...+190°C; Pressure range 0...10bar; DN 250mm; Length 68mm

GL127-200-W

Globe valve; PN16; Body Ductile iron EN-GJS-400-15; Seat, Cone, Stem Stainless steel 1.4021; Handwheel Steel; Bellow 1.4541; Rising stem; Medium temperature -10...+350°C; Pressure range 0...16bar; DN 200mm; Length 600mm

BUW6-400-DSS-G

Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner Silicone; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+190°C; Pressure range 0...16bar; DN 400mm; Length 102mm

BULA-150-CSRS-S12-A3C01

Butterfly valve with pneumatic actuator; Lug type; Length According to EN558−1 R20; Body Steel; Disc 1.4408; Shaft 1.4542; Seat RTFE; Nominal flange pressure PN16; Medium temperature -10...+230°C; Pressure range 0...16bar; ATEX II 2G/D c TX; DN 150mm; Length 56mm; Single acting actuator PAS1805-L; Low temperature equipment; Control pressure 5,5...8bar; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; Certificate TR CU; With valve pass And Verify Safety; Notch impact test

BUW2-450-DSE-G

Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN6/10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...10bar; DN 450mm; Length 114mm

GL141-100-W

Globe valve; PN16; Body; Seat 1.4408; Cone, Stem 1.4571; Handwheel Cast iron; Packing gland Graphite; Metal sealing; Rising stem; Medium temperature -10…+400°C; Pressure range 0...16bar

BULU-250-SSRS-B-A

Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body And Disc 1.4408; Shaft 1.4542; Seat RTFE; Medium temperature -60...+230°C; DN 250mm; Length 69mm; Pressure range 0…20bar; Nominal flange pressure ANSI150; ATEX Ex II 2GD c TX

1062684

Balancing valve; Nominal diameter DN125; PN6; Max. operating pressure 6bar; Material: GG25; Wafer type

AZ1VN2ISE2-5-250-B

Knife gate valve with handwheel; Wafer type; Non rising stem; Body Duplex 1.4462; Gate Duplex SAF 2205; Soft sealed EPDM; Packing PTFE-Synthetic/EPDM; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 250mm; Length 69mm; Pressure range 0-10bar

GL123-100-W-C

Globe valve; PN40; With control cone; Body 1.4408; Seat, Cone, Stem Stainless steel 1.4401; Handwheel Steel; Packing gland Graphite; Back seal; Metal sealing; Non rising stem; Medium temperature -10..+400°C; DN 100mm; Length 350mm; Pressure range 0-40bar
