Valves, butterfly valves and gate valves - manually operated

List prices PL
A1V2H3-5V-200-B01
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7; Gate 1.4301; Soft sealed FKM; Packing PTFE-Synthetic/FKM; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature 0...+120°C; DN 200mm; Length 60mm; Pressure range 0...10bar; ATEX zone 1 and 21
A1V2H3-5V-250-B01
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7; Gate 1.4301; Soft sealed FKM; Packing PTFE-Synthetic/FKM; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature 0...+120°C; DN 250mm; Length 70mm; Pressure range 0...10bar; ATEX zone 1 and 21
A1V2H3-5V-65-B01
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250; Gate 1.4301; Soft sealed FKM; Packing PTFE-Synthetic/FKM; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature 0...+180°C; DN 65mm; Length 40mm; Pressure range 0-10bar; ATEX zone 1 and 21
A1V2H3-8-100-B
Shut-off gate valve wafer type DN100, PN10 body GG25, gate plate 1.4301 seat seal FKM, packing PTFE/FKM handwheel with rising stem screws in stainless steel
A1V2H3-8-150-B
Shut-off gate valve wafer type DN150, PN10 body GG25, gate plate 1.4301 seat seal FKM, packing PTFE/FKM handwheel with rising stem screws in stainless steel
A1V2H3-8-250-B
Knife gate valve, DN250, PN10 body GG25, gate 1.4301 seat seal FKM, packing PTFE/FKM with handwheel, all screws stainless steel
A1V2H5-5-300-B
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7; Gate 1.4301; Soft sealed NBR; Packing PTFE-Synthetic/EPDM; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 300mm; Length 70mm; Pressure range 0-6bar
A1V2H5-5-350-B
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250; Gate 1.4301; Soft sealed NBR; Packing PTFE-Synthetic/EPDM; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 350mm; Length 96mm; Pressure range 0-5bar
A1V2H5-5M-200-B-01
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7; Gate 1.4301; Soft sealed NBR; Packing PTFE-Synthetic/NBR; Scraper; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -20...+90°C; DN 200mm; Length 60mm; Pressure range 0-10bar
A1V2H5-5M-80-B-01
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7; Gate 1.4301; Soft sealed NBR; Packing PTFE-Synthetic/NBR; Scraper; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -20...+90°C; DN 80mm; Length 50mm; Pressure range 0-10bar
A1V2H6W-Z-400-B
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7; Gate 1.4301; Soft sealed Silicone/PTFE/FDA; Packing Plascoat; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -25...+200°C; DN 400mm; Length 100mm; Pressure range 0-6bar
A1V2HS2-5-80-PIB
Knife gate valve with handwheel; Wafer type; Rising stem; Body Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7; Gate 1.4401; Soft sealed EPDM; Packing PTFE-Synthetic/EPDM; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -10...+90°C; Prepared for 2 inductive switches MSU03, MSU04, MSU05; DN 80mm; Length 50mm; Pressure range 0...10bar
A1V2HS5-5N-100-PIB
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250; Gate 1.4408; Soft sealed NBR; Packing PTFE-Synthetic/NBR; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 100mm; Length 50mm; Pressure range 0-10bar; Prepared for 2 inductive limit switches M18
A1V2HS5-5N-250-PIB
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250; Gate 1.4408; Soft sealed NBR; Packing PTFE-Synthetic/NBR; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 250mm; Length 70mm; Pressure range 0-6bar; Prepared for 2 inductive limit switches M18
A1V2HS5-5N-300-B
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250; Gate 1.4408; Soft sealed NBR; Packing PTFE-Synthetic/NBR; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 300mm; Length 70mm; Pressure range 0-6bar
A1V2HS5-5N-300-PIB
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250; Gate 1.4408; Soft sealed NBR; Packing PTFE-Synthetic/NBR; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 300mm; Length 70mm; Pressure range 0-6bar; Prepared for 2 inductive limit switches M18
A1V2HS5-5N-50-B
Knife gate valve with handwheel; Wafer type; Rising stem; Body Cast iron EN-GJL-250; Gate 1.4408; Soft sealed NBR; Packing PTFE-Synthetic/NBR; Screws Stainless steel; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 50mm; Length 40mm; Pressure range 0-10bar
A1V2I2-5-100-01
Knife gate valve with handwheel; Wafer type; Rising stem; Body 1.4408; Gate 1.4401; Soft sealed EPDM; Packing PTFE-Synthetic/EPDM; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 100mm; Length 50mm; Pressure range 0-10bar; Incl. Inspection certificate EN-10204-3.1; For pressure, function and tightness
A1V2I2-5-150-01
Knife gate valve with handwheel; Wafer type; Rising stem; Body 1.4408; Gate 1.4401; Support plate Stainless steel; Soft sealed EPDM; Packing PTFE-Synthetic/EPDM; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 150mm; Length 60mm; Pressure range 0-10bar; Stem extension 6000mm; Handwheel Bracket Steel; With position indicator
A1VN2I2-5-250
Knife gate valve with handwheel; Wafer type; Non rising stem; Body 1.4408; Gate 1.4401; Soft sealed EPDM; Packing PTFE-Synthetic/EPDM; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90°C; DN 250mm; Length 70mm; Pressure range 0-10bar
