Valves, butterfly valves and gate valves - manually operated

List prices PL
BUW6-065-DSE-B-S
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Medium temperature -10...+130°C; Silicone-free; DN 65mm; Length 46mm; Pressure range 0…16bar; Flange PN10/16/ANSI150
BUW6-080-DSE-B-S
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Medium temperature -10...+130°C ; Silicone-free; DN 80mm; Length 46mm; Pressure range 0…16bar; Flange PN10/16/ANSI150
BUW6-100-DSE-B-S
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Medium temperature -10...+130°C; Silicone-free; DN 100mm; Length 52mm; Pressure range 0…16bar; Flange PN10/16/ANSI150
BUW6-125-DSE-B-S
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Medium temperature -10...+130°C; Silicone-free; DN 125mm; Length 56mm; Pressure range 0…16bar; Flange PN10/16/ANSI150
BUW6-150-DSE-B-S
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Medium temperature -10...+130°C; DN 150mm; Length 56mm; Pressure range 0…16bar; Flange PN10/16/ANSI150
BUW6-200-DSE-B-S
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Medium temperature -10...+130°C; Silicone-free; DN 200mm; Length 60mm; Pressure range 0…16bar; Flange PN10/16/ANSI150
BUW6-250-DSE-B-S
Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Medium temperature -10...+130°C; Silicone-free; DN 250mm; Length 68mm; Pressure range 0…16bar; Flange PN10/16/ANSI150
BUW6-050-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; Silicone-free; DN 50mm; Length 43mm
BUW6-065-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; Silicone-free DN 65mm; Length 46mm
BUW6-080-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; Silicone-free; DN 80mm; Length 46mm
BUW6-100-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; Silicone-free; DN 100mm; Length 52mm
BUW6-125-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 125mm; Length 56mm; Silicone-free
BUW6-150-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; Silicone-free; DN 150mm; Length 56mm
BUW6-200-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 200mm; Length 60mm
BUW6-250-DSE-L-S
Butterfly valve with hand lever Series BUW6-DSE-L; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+130°C; Pressure range 0...16bar; DN 250mm; Length 68mm
C3J-CH009-80-V
Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-CH009-50-V
Inspection certificate EN-10204-3.1; For material, pressure and tightness
SE27-12-STW-03
Angle seat-Globe valve Series SE27; Manual operated; Body AISI 316; Cone, Stem, Head end Stainless steel AISI 316Ti; Handwheel Steel Plastic coated; Seat seal PTFE; Packing PTFE filled with coal; Back seal; PTFE; Rising stem; Medium temperature -30…+200°C; Pressure range 0...40bar; Thread G1/2"; DN 15mm; Length 65mm; Incl. Certificate according to EN 10204-2.2
C3J-BUW6-050-DSV
Inspection certificate EN-10204-3.1; For material, pressure and tightness
BUW6-100-DSVS-B
Butterfly valve with bare shaft Series BUW6-DSV-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4401; Liner FKM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+200°C; Pressure range 0...16bar; DN 100mm; Length 52mm
