Valves, butterfly valves and gate valves - manually operated

List prices PL
C3J-BULY-125-DSE-04
Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-100-DSE-B-04
Butterfly valve with bare shaft Series BUL-B-04; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated C5-M According to EN-ISO 12944 RAL5009; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
C3J-BULY-100-DSE-04
Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-100-DSE-B-3C04
Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated C5-M According to EN-ISO 12944 RAL5009; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-125-DSE-B-05
Butterfly valve with bare shaft Series BUL-B-05; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated C5-M According to EN-ISO 12944 RAL5009; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-125-DSE-B-3C05
Butterfly valve with bare shaft Series BUL-B-3C05; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated C5-M According to EN-ISO 12944 RAL5009; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BULY-125-DSE-05
Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BUW6-250-DSE
Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BULY-200-CSN
Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BULY-200-CSN-01
Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-200-CSN-B-01
Butterfly valve with bare shaft Series BUL-CSN-B-01; Lug type; Length According to EN558−1 R20; Body Steel 1.0619 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -10...+100°C; DN 200mm; Length 60mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-200-CSN-L
Butterfly valve with hand lever Series BUL-CSN-L; Lug type; Length According to EN558−1 R20; Body Steel 1.0619 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -10...+100°C; DN 200mm; Length 60mm; Pressure range 0-16bar; Flange ANSI150
BULY-200-CSN-L-01
Butterfly valve with hand lever Series BUL-CSN-L-01; Lug type; Length According to EN558−1 R20; Body Steel 1.0619 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -10...+100°C; DN 200mm; Length 60mm; Pressure range 0-16bar; Flange ANSI150; Flange thread UNC
C3Q-BULY-200-CSN-01
Notch impact test -29°C; Inspection certificate EN-10204-3.1
BULY-200-CSN-B-3E01
Butterfly valve with bare shaft Series BUL-CSN-B-3E01; Lug type; Length According to EN558−1 R20; Body Steel 1.0619 Epoxy coated C4-H According to EN-ISO 12944 RAL7038; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -25...+100°C; DN 200mm; Length 60mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Notch impact test -29°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BULY-200-CSN-G-3E01
Butterfly valve with manual gear box Series BUL-G-3E01; Lug type; Length According to EN558−1 R20; Body Steel 1.0619 Epoxy coated C4-H According to EN-ISO 12944 RAL7038; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -25...+100°C; DN 200mm; Length 60mm; Pressure range 0-16bar; Flange ANSI150; Flange thread UNC; Notch impact test -29°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BUW6-350-CSN-A
Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3Q-BUW6-350-CSN-A
Notch impact test -29°C; Inspection certificate EN-10204-3.1
BULY-150-DSE-L-03
Butterfly valve with hand lever Series BUL-L-03; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated C4-H According to EN-ISO 12944 RAL5009; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 150mm; Length 56mm; Pressure range 0-16bar; Flange ANSI150; Flange thread UNC
APKTGB0190
Mounting bracket For butterfly valve; DN500-F14/F16-Square 36; Actuator F16-46
