STASTO Solenoid valves: Reliable solutions for liquids and gases

Solenoid valves for liquids and gases

SK-SL066-15-N-03

seal kit for solenoid valve SL066-15-N-03

C3S-ST059-250

inspection certificate EN-10204-3.1; for material and pressure

SL009-114-E-01-BDA08024CS-C003-32-6

SL009-114-E-01
2/2-way solenoid valve; Pilot-operated; NC; Body Brass; Tube Stainless steel One-piece; Seal EPDM; Medium temperature -10...+60°C; G 11/4"; DN 35mm; Pressure AC/DC 0,2-10bar; Length 144mm; Free of oil and grease for oxygen
BDA08024CS
coil type BDA; standard; connector size 32mm; voltage 24VDC
C003-32-6
connector; connector size 32mm; standard; voltage 0...250VAC/DC

SL134-38-22

2/2-way solenoid valve; combined operated; NC; body brass; seal PTFE; medium temperature -40...+80°C; DN 13,5; G 3/8"; length: 67mm; pressure range 0…40bar; voltage 230VAC

SL067-20-14-01

2/2-way solenoid valve; pilot-operated; NC; body AISI 316Ti; seal NBR; G 1/2"; DN 27mm; pressure 0,3...12bar; voltage 110V/50Hz-120V/60Hz; incl. connector; sealed plunger zone; with adjustable closing delay

SL076-80-N-03-01

2/2-way solenoid valve; Flange connection; Combined operated; NC; Body Cast iron EN-GJL-250; Seal NBR; Nominal diameter 80mm; PN16; Medium temperature 0...+80°C; Voltage 24VDC; Operating pressure 0...2bar

SL057-20-V-03-02

2/2-way solenoid valve; Combined operated; NC; Body Brass; Medium temperature -10...+60°C; Incl. coil and connector; Seal FKM; G 2"; DN 50mm; Pressure 0...3bar; Length 168mm; Voltage 24VDC; ATEX According to 2014/34/EU

SL076-150-22

2/2-way solenoid valve; Flange connection; Combined operated; NC; Body Cast iron EN-GJL-250; Seal NBR; Nominal diameter 150mm; PN16; Medium temperature -10...+80°C; Voltage 230VAC; Operating pressure 0...2bar; Length 480mm

21W4KV250-BDA08223DS-C003-32-6

21W4KV250
2/2-way solenoid valve; Pilot-operated; NC; Body Brass; Tube Stainless steel One-piece; Seal FKM; Medium temperature -10...+140°C; Standard coil BDA; Connector size 32mm; G 1"; DN 25mm; Pressure AC/DC 0,2-16bar; Length 104mm
BDA08223DS
Coil Type BDA; Standard; Connector size 32mm; Voltage 220-230V/50-60Hz
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC

KTGIH6K1B25

Seal kit; Suitable to series 21IH.K1B; Dimension 1"; Seal NBR

SL021-FL-1,5-C03

3/2-way solenoid valve; Directly operated; NC; Body Brass; Tube Stainless steel One-piece; Seal FKM; Medium temperature -10...+120°C; Coil BDV; Voltage 24VDC; Connector size 32mm; Flange; DN 1,5/2,5mm; Pressure AC/DC 0...15bar; Length 40mm

SL134-114-22-01

2/2-way solenoid valve; Combined operated; NC; Body Brass; Seal PTFE; Medium temperature -40...+40°C; DN40; G 11/4"; Length: 140mm; Pressure range 0…40bar; Voltage 230VAC

SL097-114-V-22-01

2/2-way solenoid valve Series SL097; Pilot-operated; NC; Piston type; Body Brass; Seal FKM; Connector size 32mm; Pressure 0,5…40bar; Medium temperature -10...+80°C; Incl. coil; With connector; G 11/4"; DN 32mm; Length 140mm; Voltage 230VAC; ATEX Ex II 2G Ex mb IIC T4 Gb And Ex II 2D Ex mb tb IIIC T130°C Db

SL078-10-V-03-01

2/2-way solenoid valve; Combined operated; NO; Body Brass; Medium temperature 0...+60°C; including solenoid coil and terminal box; Seal FKM; G 1"; DN 25mm; Pressure 0...16bar; Length 96mm; Voltage 24VDC; ATEX Ex II 2G Ex e mb IIC T4 Gb And Ex II 2D Ex mb tb IIIC T130°C Db
