Ball valves - automatically operated

List prices PL
BA622-25-D0-A-01
Ball valve with pneumatic actuator; Flange PN63; According to ATEX; Body, Ball 1.4401; Seals PTFE- Reinforced with carbographite/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+198°C; Pressure range 0...63bar; Nominal diameter 25mm; Length 65mm; Actuator PAD063
BA622-50-D0-A-01
Ball valve with pneumatic actuator; Flange PN63; According to ATEX; Body, Ball 1.4401; Seals PTFE- Reinforced with carbographite/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+198°C; Pressure range 0...63bar; Nominal diameter 50mm; Length 100mm; Actuator PAD085
BA622-65-D0-A-01
Ball valve with pneumatic actuator; Flange PN63; According to ATEX; Body, Ball 1.4401; Seals PTFE- Reinforced with carbographite/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+198°C; Pressure range 0...63bar; Nominal diameter 65mm; Length 125mm; Actuator PAD115
BA622-D80-0Q-A
Flanged ball valve with electrical actuator; Protection class IP68; ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb; Body, Ball 1.4401; Seals Fibre-glass-reinforced PTFE/PTFE/Graphoil/FKM; Medium temperature -20...+160°C; DN 80mm; Pressure range 0-63bar; Flange PN63; Length 150mm; Operating time 30s; Voltage 100-240V/50-60Hz; 100-350VDC
BA625-50-0H
Flanged ball valve with electrical actuator; Flange PN16, Full bore; Body Ductile iron; Seals PTFE/FPM; Pressure range 0...16bar; Medium temperature -20...+60°C; Nominal diameter 50mm; Length 150mm; Length EN558 R27; TA-Luft certification; DVGW-gas-approved; Operating time 27s; Voltage 100-240VAC
BA630-34-S2
Ball valve with pneumatic actuator; 4/2-way-Design; Body Zinc plated steel; Ball Steel Hard chrome plated; Seals PTFE/FKM; Single acting actuator; Control pressure 4...8bar; Medium temperature -10...+150°C; G 3/4"; Nominal diameter 20mm; Pressure range 0-40bar; Length 123mm; Actuator PAS1153; Ball X
BA632-20-D0
Flanged ball valve with pneumatic actuator; Flange PN100; Body Steel; Seals POM/NBR; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+100°C; Pressure range 0...100bar; Nominal diameter 20mm; Length DIN 3202 F1; Actuator PAD063
BA636-25-S0
Flanged ball valve with pneumatic actuator; Length According to EN558−1 R1; Body 1.4571; Ball 1.4404; Seals Fibre-glass-reinforced PTFE/FEP; Single acting actuator; Control pressure 5,5...8bar; Medium temperatureMax. 200°C Steam; Nominal diameter 25mm; Pressure range 0-16bar; Flange PN16; Length 16mm; Actuator PAS0855
BA636-40-S0
Flanged ball valve with pneumatic actuator; Length According to EN558−1 R1; Body 1.4571; Ball 1.4404; Seals Fibre-glass-reinforced PTFE/FEP; Single acting actuator; Control pressure 5,5...8bar; Medium temperatureMax. 200°C Steam; Nominal diameter 40mm; Pressure range 0-16bar; Flange PN16; Length 200mm; Actuator PAS1155
BA637-20-B
Ball valve; Female thread; Material PVDF; Seals PTFE/FKM; RP 2"; Nominal diameter 50mm; Pressure range 0...16bar
BA639-50-D0
Flanged ball valve with pneumatic actuator; Body Zinc plated steel; Ball Hard chrome plated steel; Seals POM/FPM; DN 50mm; Pressure range 0-63bar; Flange PN63; Length 230mm, EN558-F1; Double acting actuator; Control pressure 5,5...8bar; Actuator PAD100
BA640-14-L-01
Ball valve; Female thread According to DIN ISO 228/1; Body Steel; Ball Stainless steel; Seals PTFE/EPDM; Connection 1/4" Nominal diameter 6mm; Pressure range Acetylene 0...1,5bar; Length 50mm; Actuation Hand lever
BA649-12-0F
Ball valve with electrical actuator; 3-way-type; Sealing on two sides; Pressure inlet just in front; Female thread; Body Zinc plated steel; Ball Hard chrome plated steel; Seals POM/NBR; Medium temperature -10...+90°C; G 1/2"; DN 15mm; Pressure range 0-500bar; Length 75mm; Operating time 10s; Voltage 100-240VAC; Ball L
BA649-34-D0
High pressure ball valve; 3-way-type; Sealing on two sides; Ball L; Pressure inlet just in front; Female thread; Body Steel; Ball Hard chrome plated steel; Seals POM/NBR; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10…+90°C; G 3/4"; Nominal diameter 20mm; Pressure range 0-320bar; Length 80mm; Actuator PAD085
BA659-50-0H
Ball valve with electrical actuator; Butt weld ends; Body, Ball 1.4404; Seals PTFE/EPDM; Medium temperature -45...+150°C; DN 50mm; Pressure range 0-25bar; Length 136mm; Operating time 9s; Voltage 100-240VAC
BA659-50-B
Ball valve made of stainless steel; Full bore; Three-parts type; Butt weld ends; Body, Ball 1.4404; Seals PTFE/EPDM; Medium temperature -45...+150°C; Nominal diameter 50mm; Pressure range 0-25bar; Length 136mm
BA659-80-0H
Ball valve with electrical actuator; Butt weld ends; Body, Ball 1.4404; Seals PTFE/EPDM; Medium temperature -45...+150°C; DN 80mm; Pressure range 0-16bar; Length 168mm; Operating time 27s; Voltage 100-240VAC
BA659-80-B
Ball valve made of stainless steel; Full bore; Three-parts type; Butt weld ends; Body, Ball 1.4404; Seals PTFE/EPDM; Medium temperature -45...+150°C; Nominal diameter 80mm; Pressure range 0-16bar; Length 168mm
BA666-22L-B
High pressure ball valve; Male thread According to DIN 2353; Body Zinc plated steel; Ball Stainless steel; Seals PEEK/FKM; Medium temperature -10…+160°C; Connection 22L/M30x2; Nominal diameter 20mm; Pressure range 0-320bar; Length 110mm; Flange F05 For mounting an actuator; Square 14mm
BA666-22L-D0
Ball valve with pneumatic actuator; Male thread According to DIN 2353; Body Zinc plated steel; Ball Stainless steel; Seals PEEK/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+160°C; Connection 22L/M30x2; Nominal diameter 20mm; Pressure range 0...320bar; Length 110mm; Actuator PAD063
