Armatures

List prices PL
21PW4K0T120-BDA08042AS-C003-31-CV20-6
21PW4K0T120
2/2-way solenoid valve Series 21PW; Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,5-18bar; Function NC; Length 67mm; Standard coil BDA
BDA08042AS
Coil Type BDA; Standard; Connector size 32mm; Voltage 42V/50Hz
C003-31-CV20-6
Connector; Connector size 32mm; With moulded PVC-cable (2 m); Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series 21PW
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 42V/50Hz AC With moulded PVC-cable (2 m) CE 21PW4K0T120-BDA08042AS-C003-31-CV20-6
SL012-10-BDV08024DY-C003-32-LV-2
SL012-10
2/2-way solenoid valve Series SL012; Pilot-operated; NC; Piston type; Body Brass; Tube Stainless steel One-piece; Seal Fibre-glass-reinforced PTFE; Medium temperature -40...+180°C; Standard coil BDV; Connector size 32mm; G 1"; DN 25mm; Pressure AC/DC 0,9-10bar; Length 93mm
BDV08024DY
Coil Type BDV; For humid area; Approval CSA/UL/VDE; Connector size 32mm; Voltage 24V/50-60Hz
C003-32-LV-2
Connector; Connector size 32mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC
To Series: 2/2-way solenoid valve Series SL012
Female thread DN Length Pressure AC/DC Voltage Approval Design Voltage type Type
G 1" 25 mm 93 mm 0,9...10 bar 24V/50-60Hz UL/CSA/VDE With integrated LED-yellow and VDR AC SL012-10-BDV08024DY-C003-32-LV-2
21PW4K0T120-BDA08048AS-C003-32-6
21PW4K0T120
2/2-way solenoid valve Series 21PW; Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,5-18bar; Function NC; Length 67mm; Standard coil BDA
BDA08048AS
Coil Type BDA; Standard; Connector size 32mm; Voltage 48V/50Hz
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series 21PW
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 48V/50Hz AC Standard CE 21PW4K0T120-BDA08048AS-C003-32-6
SL012-10-BDV08110AY-C003-32-6
SL012-10
2/2-way solenoid valve Series SL012; Pilot-operated; NC; Piston type; Body Brass; Tube Stainless steel One-piece; Seal Fibre-glass-reinforced PTFE; Medium temperature -40...+180°C; Standard coil BDV; Connector size 32mm; G 1"; DN 25mm; Pressure AC/DC 0,9-10bar; Length 93mm
BDV08110AY
Coil Type BDV; For humid area; Approval CSA/UL/VDE; Connector size 32mm; Voltage 110V/50Hz,120V/60Hz
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series SL012
Female thread DN Length Pressure AC/DC Voltage Approval Design Voltage type Type
G 1" 25 mm 93 mm 0,9...10 bar 110V/50Hz, 120V/60Hz UL/CSA/VDE Standard AC SL012-10-BDV08110AY-C003-32-6
21PW4K0T120-BDA08048AS-C003-31-CV20-6
21PW4K0T120
2/2-way solenoid valve Series 21PW; Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,5-18bar; Function NC; Length 67mm; Standard coil BDA
BDA08048AS
Coil Type BDA; Standard; Connector size 32mm; Voltage 48V/50Hz
C003-31-CV20-6
Connector; Connector size 32mm; With moulded PVC-cable (2 m); Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series 21PW
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 48V/50Hz AC With moulded PVC-cable (2 m) CE 21PW4K0T120-BDA08048AS-C003-31-CV20-6
SL012-10-BDV08110AY-C003-31-CV20-6
SL012-10
2/2-way solenoid valve Series SL012; Pilot-operated; NC; Piston type; Body Brass; Tube Stainless steel One-piece; Seal Fibre-glass-reinforced PTFE; Medium temperature -40...+180°C; Standard coil BDV; Connector size 32mm; G 1"; DN 25mm; Pressure AC/DC 0,9-10bar; Length 93mm
BDV08110AY
Coil Type BDV; For humid area; Approval CSA/UL/VDE; Connector size 32mm; Voltage 110V/50Hz,120V/60Hz
C003-31-CV20-6
Connector; Connector size 32mm; With moulded PVC-cable (2 m); Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series SL012
Female thread DN Length Pressure AC/DC Voltage Approval Design Voltage type Type
G 1" 25 mm 93 mm 0,9...10 bar 110V/50Hz, 120V/60Hz UL/CSA/VDE With moulded PVC-cable (2 m) AC SL012-10-BDV08110AY-C003-31-CV20-6
21PW4K0T120-BDA08110DS-C003-32-6
21PW4K0T120
2/2-way solenoid valve Series 21PW; Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,5-18bar; Function NC; Length 67mm; Standard coil BDA
BDA08110DS
Coil Type BDA; Standard; Connector size 32mm; Voltage 110V/50-60Hz
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series 21PW
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 110V/50-60Hz AC Standard CE 21PW4K0T120-BDA08110DS-C003-32-6
SL012-10-BDV08110AY-C003-32-LV-1
SL012-10
2/2-way solenoid valve Series SL012; Pilot-operated; NC; Piston type; Body Brass; Tube Stainless steel One-piece; Seal Fibre-glass-reinforced PTFE; Medium temperature -40...+180°C; Standard coil BDV; Connector size 32mm; G 1"; DN 25mm; Pressure AC/DC 0,9-10bar; Length 93mm
BDV08110AY
Coil Type BDV; For humid area; Approval CSA/UL/VDE; Connector size 32mm; Voltage 110V/50Hz,120V/60Hz
C003-32-LV-1
Connector; Connector size 32mm; With integrated LED-yellow and VDR; Voltage 230VAC/DC
To Series: 2/2-way solenoid valve Series SL012
Female thread DN Length Pressure AC/DC Voltage Approval Design Voltage type Type
G 1" 25 mm 93 mm 0,9...10 bar 110V/50Hz, 120V/60Hz UL/CSA/VDE With integrated LED-yellow and VDR AC SL012-10-BDV08110AY-C003-32-LV-1
21PW4K0T120-BDA08110DS-C003-31-CV20-6
21PW4K0T120
2/2-way solenoid valve Series 21PW; Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,5-18bar; Function NC; Length 67mm; Standard coil BDA
BDA08110DS
Coil Type BDA; Standard; Connector size 32mm; Voltage 110V/50-60Hz
C003-31-CV20-6
Connector; Connector size 32mm; With moulded PVC-cable (2 m); Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series 21PW
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 110V/50-60Hz AC With moulded PVC-cable (2 m) CE 21PW4K0T120-BDA08110DS-C003-31-CV20-6
SL012-10-GDV14230AY-C003-32-6
SL012-10
2/2-way solenoid valve Series SL012; Pilot-operated; NC; Piston type; Body Brass; Tube Stainless steel One-piece; Seal Fibre-glass-reinforced PTFE; Medium temperature -40...+180°C; Standard coil BDV; Connector size 32mm; G 1"; DN 25mm; Pressure AC/DC 0,9-10bar; Length 93mm
GDV14230AY
Coil Type GDV/GDH; For higher pressures/temperatures; Connector size 32mm; Voltage 230V/50Hz, 240V/60Hz; Approval CSA/UL/VDE
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series SL012
Female thread DN Length Pressure AC/DC Voltage Approval Design Voltage type Type
G 1" 25 mm 93 mm 0,9...10 bar 230V/50Hz-240V/60Hz UL/CSA/VDE Standard - SL012-10-GDV14230AY-C003-32-6
21PW4K0T120-BDA08110DS-C003-32-LV-1
21PW4K0T120
2/2-way solenoid valve Series 21PW; Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,5-18bar; Function NC; Length 67mm; Standard coil BDA
BDA08110DS
Coil Type BDA; Standard; Connector size 32mm; Voltage 110V/50-60Hz
C003-32-LV-1
Connector; Connector size 32mm; With integrated LED-yellow and VDR; Voltage 230VAC/DC
To Series: 2/2-way solenoid valve Series 21PW
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 110V/50-60Hz AC With integrated LED-yellow and VDR CE 21PW4K0T120-BDA08110DS-C003-32-LV-1
2/2-way solenoid valve Series SL012

2/2-way solenoid valve Series SL012

Pilot-operated; NC; Piston type; Body Brass; Tube Stainless steel One-piece; Seal Fibre-glass-reinforced PTFE; Medium temperature -40...+180°C; Standard coil BDV; Connector size 32mm

2/2-Wege-Magnetventil Serie SL012
To Series: 2/2-way solenoid valve Series SL012
Varianten
Female thread DN Length Pressure AC/DC Voltage Approval Design Voltage type Type Sequence
G 1" 25 mm 93 mm 0,9...10 bar 230V/50Hz-240V/60Hz UL/CSA/VDE Standard AC SL012-10-BDV08230AY-C003-32-6 20110039
G 1" 25 mm 93 mm 0,9...10 bar 230V/50Hz-240V/60Hz UL/CSA/VDE With moulded PVC-cable (2 m) AC SL012-10-BDV08230AY-C003-31-CV20-6 20110040
21PW4K0T120-BDA08223DS-C003-32-6
21PW4K0T120
2/2-way solenoid valve Series 21PW; Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,5-18bar; Function NC; Length 67mm; Standard coil BDA
BDA08223DS
Coil Type BDA; Standard; Connector size 32mm; Voltage 220-230V/50-60Hz
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC
To Series: 2/2-way solenoid valve Series 21PW
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 220-230V/50-60Hz AC Standard CE 21PW4K0T120-BDA08223DS-C003-32-6
SL012-10-BDV08230AY-C003-32-LV-1
SL012-10
2/2-way solenoid valve Series SL012; Pilot-operated; NC; Piston type; Body Brass; Tube Stainless steel One-piece; Seal Fibre-glass-reinforced PTFE; Medium temperature -40...+180°C; Standard coil BDV; Connector size 32mm; G 1"; DN 25mm; Pressure AC/DC 0,9-10bar; Length 93mm
BDV08230AY
Coil Type BDV; For humid area; Approval CSA/UL/VDE; Connector size 32mm; Voltage 230V/50Hz, 240V/60Hz
C003-32-LV-1
Connector; Connector size 32mm; With integrated LED-yellow and VDR; Voltage 230VAC/DC
To Series: 2/2-way solenoid valve Series SL012
Female thread DN Length Pressure AC/DC Voltage Approval Design Voltage type Type
G 1" 25 mm 93 mm 0,9...10 bar 230V/50Hz-240V/60Hz UL/CSA/VDE With integrated LED-yellow and VDR AC SL012-10-BDV08230AY-C003-32-LV-1
2/2-way solenoid valve Series 21PW

2/2-way solenoid valve Series 21PW

Pilot-operated; Relief valve for compressors; Body Brass; Stainless steel tube with soldered hexagon made of brass; Seal PTFE/FKM; Medium temperature -10...+120°C; Connector size 32mm

2/2-Wege-Magnetventil Serie 21PW 2/2-Wege-Magnetventil Serie 21PW
To Series: 2/2-way solenoid valve Series 21PW
Grundversion
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type Sequence
G 1/2" 12 mm 67 mm NC 0,5...20 bar 0,5...15 bar - - - - 21PW4K0T120-GDV 20110044
Varianten
Female thread DN Length Function Pressure AC Pressure DC Voltage Voltage type Design Approval Type Sequence
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 220-230V/50-60Hz AC With moulded PVC-cable (2 m) CE 21PW4K0T120-BDA08223DS-C003-31-CV20-6 20110042
G 1/2" 12 mm 67 mm NC 0,5...18 bar - 220-230V/50-60Hz AC With integrated LED-yellow and VDR CE 21PW4K0T120-BDA08223DS-C003-32-LV-1 20110043
G 1/2" 12 mm 67 mm NC 0,5...20 bar 0,5...15 bar 12VDC - Standard CE 21PW4K0T120-GDV-GDH14012CS-C003-32-6 20110045
G 1/2" 12 mm 67 mm NC 0,5...20 bar 0,5...15 bar 12VDC - With moulded PVC-cable (2 m) CE 21PW4K0T120-GDV-GDH14012CS-C003-31-CV20-6 20110046
