BUW6-150-DSE-S22-ABS54-C001-03-C002-31-6-EB0X01
BUW6-150-DSE-S22
Butterfly valve with pneumatic actuator Series BUW6-DSE-S2; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+130°C; Pressure range 0...10bar; DN 150mm; Length 56mm; Actuator PAS1605
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic
Country of origin: Italy
Weight: 39.148 Kg
Short Itemnumber: BUW6150DSES22ABS54C00103C002316EB0X01
BUW6-150-DSE-S22
Butterfly valve with pneumatic actuator Series BUW6-DSE-S2; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc AISI 316; Shaft AISI 430; Liner EPDM; Nominal flange pressure PN10/16/ANSI150; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+130°C; Pressure range 0...10bar; DN 150mm; Length 56mm; Actuator PAS1605
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic
| dimension | |
|---|---|
| Attachment interface VDI/VDE 3845 | 80x30x20 |
| Attachment interface 2 VDI/VDE 3845 | 80x30x30 |
| Valve interface Namur | 1/4" |
| DN | 150 mm |
| Length | 56 mm |
| Designs | |
| Connector size | 22 |
| Switch type | Crouzet 831613 |
| design | |
| Design | Standard |
| Electrical key figures | |
| Voltage | 24VDC / 48V/50-60Hz |
| Switching capacity | 4A/250VAC-1A/24VDC |
| pressure | |
| Pressure range | 0...10 bar |
| materials | |
| Contact material | Silver-nickel |
| Material of case | Plastic |
| characteristics | |
| Coil | C001 |
| Actuator | PAS1605 |
| Actuator 2 | PAS |
