BA497-50-D5-A

Name: BA497-50-D5-A
Brand: STASTO
SKU: BA497-50-D5-A
Price: 3378.8 PLN
Availability: InStock

Flanged ball valve with pneumatic actuator Series BA497-D5-A; ATEX II 2 G/D; Fire-safe; TA-Luft; Full bore; Body Steel; Ball 1.4301; Seals TFM-MPTFE/PTFE/Graphoil; Stem sealing V-Pack; Medium temperature -20...+180°C; Double acting actuator; Control pressure 6...8bar; Nominal diameter 50mm; Flange PN16/40; Pressure range 0...40bar; Length 83mm; Actuator PAD075

Intrastat No.: 84818081
Country of origin: Italy
Weight: 13.27 Kg
Short Itemnumber: BA49750D5A

flanged ball valve with pneumatic actuator series BA497-D5-A; ATEX II 2 G/D; fire-safe; TA-Luft; full bore; body steel; ball AISI 304; seals TFM-MPTFE/PTFE/Graphoil; stem sealing V-Pack; medium temperature -20...+180°C; double acting actuator; control pressure 6...8bar; nominal diameter 50mm; flange PN16/40; pressure range 0...40bar; length 83mm; actuator PAD075

3.378,80 zł 3378.8 PLN 3.378,80 zł

Design
- ATEX

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

Design

ATEX

BA497-50-L-A x 1.0

BA497-50-L-A

Flanged ball valve Series BA497-L-A; ATEX II 2 G/D; Fire-safe; TA-Luft; Full bore; Body Steel, Ball 1.4301; Seals TFM-MPTFE/PTFE/Graphoil; Stem sealing V-Pack; Medium temperature -20...+180°C; Nominal diameter 50mm; Pressure range 0...40bar; Flange PN16/40; Length 83mm

Add to Cart

PAD075 x 1.0

Pneumatic actuator PAD075

Pneumatic actuator Series PAD; ATEX II 2 G/D; Double acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 75mm; Flange ISO5211 F05/F07; Female square 17mm; Torque at 5,5bar 66Nm

Add to Cart

RI3526 x 1.0
