Ball valve with pneumatic actuator BA233-35L-D0

Price:

2.261,20 zł
Ball valve with pneumatic actuator Series BA233 Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Ball valves for high pressure - pneumatically operated
  5. Ball valve with pneumatic actuator Series BA233
  6. BA233-35L-D0
Ball valve with pneumatic actuator BA233-35L-D0
BA233-30S-D0-ABS51-C001-22-C002-31-LVCV20-1
BA233-30S-D0-ABS51-C001-22-C002-31-LVCV20-1
2.848,10 zł
2.848,10 zł
BA233-35L-D0-ABS51-C001-03-C002-31-6
BA233-35L-D0-ABS51-C001-03-C002-31-6
2.908,40 zł
2.908,40 zł

Ball valve with pneumatic actuator BA233-35L-D0

Ball valve with pneumatic actuator Series BA233; Male thread According to ISO 8434-1 (DIN 2353); Body Zinc plated steel; Ball Steel; Seals POM/NBR; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+100°C; For liquids; Connection 35L/M45x2; Nominal diameter 25mm; Pressure range 0...350bar; Length 112mm; Actuator PAD085

Intrastat No.: 84818081
Country of origin: Italy
Weight: 6.35 Kg
Short Itemnumber:BA23335LD0
https://www.stasto.pl/web/image/product.template/139696/image_1920?unique=bbc91d7

ball valve with pneumatic actuator series BA233; male thread according to ISO 8434-1 (DIN 2353); body zinc plated steel; ball steel; seals POM/NBR; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+100°C; for liquids; connection 35L/M45x2; nominal diameter 25mm; pressure range 0...350bar; length 112mm; actuator PAD085

2.261,20 zł 2261.2 PLN 2.261,20 zł

cena na zapytanie

  • Male thread
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Type
  • Design
  • Voltage
  • Pressure range
  • Coil
  • Actuator

This combination does not exist.

Availability:
Contact Us
dimension
Male thread M45x2
DN 25 mm
Length 112 mm
Designs
Type 35L
pressure
Pressure range 0...350 bar
characteristics
Actuator PAD085
