BA043-80-T0-ABS53-C001-03-C002-31-LV-2
BA043-80-T0
Flanged ball valve with pneumatic actuator Series BA043; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 80mm; Length 122mm; Actuator PAS1255; Safety position NO
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-LV-2
connector; connector size 22mm; with integrated LED-yellow and VDR; voltage 24VAC/DC
Country of origin: Italy
Weight: 36.55 Kg
Short Itemnumber: BA04380T0ABS53C00103C00231LV2
Flanged ball valve with pneumatic actuator Series BADA; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 80mm; Length 122mm; Actuator PAS1255
| dimension | |
|---|---|
| DN | 80 mm |
| Length | 122 mm |
| pressure | |
| Pressure range | 0...16 bar |
| characteristics | |
| Actuator | PAS1255 |
