BA043-100-T0

Name: BA043-100-T0
Brand: STASTO
SKU: BA043-100-T0
Price: 7440.0 PLN
Availability: InStock

Flanged ball valve with pneumatic actuator; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; NO; Control pressure 5,5...8bar; Medium temperature -10...+160°C; Pressure range 0...16bar; Nominal diameter 100mm; Length 152mm; Actuator PAS1255

Intrastat No.: 84818081
Country of origin: Italy
Weight: 50.05 Kg
Short Itemnumber: BA043100T0

flanged ball valve with pneumatic actuator; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; NO; control pressure 5,5...8bar; medium temperature -10...+160°C; pressure range 0...16bar; nominal diameter 100mm; length 152mm; actuator PAS1255

7.440,00 zł 7440.0 PLN 7.440,00 zł

excl. tax

Brand
- STASTO

This combination does not exist.

Availability:

See availability

Add to cart

Technical specifications

Pressure range	0...16bar
Brand	STASTO

Specifications
Spare Parts

Pressure range	0...16bar
Brand	STASTO

BA043-100-L x 1.0 Pcs

Flanged ball valve BA043-100-L

Flanged ball valve Series BA043-L; Flange PN16, Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 100mm; Length 152mm

PAS1255-B x 1.0 Pcs

PAS1255-B

Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Pinion turned by 90°; Diameter 125mm; Flange ISO5211 F07/F10; Female square 22mm; Torque at 5,5bar 88,1Nm

RI3005 x 1.0 Pcs
