Knife gate valve with double acting actuator Series A1N2H2-5-PMB Store
  1. Products
  2. Armatures
  3. Valves, butterfly valves and gate valves - automatically operated
  4. Other materiales - A05
  5. Knife gate valve with double acting actuator Series A1N2H2-5-PMB
  6. A1N2H2-5-200-PM-B-ABS40-CS02400-6-14423-0525-MSU01A/2
A1N2H2-5-200-PM-B-ABS40-CS02400-6-14423-0525-MSU01A/2

A1N2H2-5-200-PM-B-ABS40-CS02400-6-14423-0525-MSU01A/2

A1N2H2-5-200-PM-B
knife gate valve with double acting actuator series A1N2H2-5-PMB; wafer type; body cast iron EN-GJL-250/ductile iron EN-GJS-500-7; gate AISI 304; soft sealed EPDM; packing PTFE-synthetic/EPDM; screws stainless steel; nominal flange pressure PN10; unidirectional sealed; control pressure 5,5...8bar; medium temperature -5...+90°C; prepared for 2 mechanical switches MSU01A; DN 200mm; length 60mm; pressure range 0…8bar
ABS40
mounted pilot valve series ABS; suitable for pneumatically operated knife gate valves; 5/2-way solenoid valve; flow control valves; silencer; mounted at cylinder; type of coil CS; connector size 16mm; 5/2-Wege-Magnetventil (K52W1014); DN gate valve 50-400mm
CS02400
coil type CS; connector size 16mm; voltage 24VDC
6-14423-0525
connector; connector size 16mm; with integrated LED-yellow and VDR; voltage 24VAC/DC
MSU01A/2
electrical position indication series MSU; Suitable for knife gate valves; Built-on mechanical limit switch (2 pieces)

Intrastat No.: 84818061
Country of origin: Spain
Weight: 35.174 Kg
Short Itemnumber: A1N2H25200PMBABS40CS024006144230525MSU01A2
