Knife gate valve with double acting actuator Series A1N-PIB Store
  1. Products
  2. Armatures
  3. Valves, butterfly valves and gate valves - automatically operated
  4. Knife gate valves - pneumatically operated
  5. Knife gate valve with double acting actuator Series A1N-PIB
  6. A1N2H2-5-150-PIB-ABS42-C001-03-C002-31-6
A1N2H2-5-150-PIB-ABS40-CS02400-6-14123-0000-S-MSU032 (Copy)

A1N2H2-5-150-PIB-ABS40-CS02400-6-14123-0000-S-MSU032 (Copy)

A1N2H2-5-150-PIB
knife gate valve with double acting actuator series A1N-PIB; wafer type; body cast iron EN-GJL-250/ductile iron EN-GJS-500-7; gate AISI 304; soft sealed EPDM; packing PTFE-synthetic/EPDM; screws stainless steel; nominal flange pressure PN10; unidirectional sealed; control pressure 5,5...8bar; medium temperature -5...+90°C; prepared for 2 inductive switches MSU03, MSU04, MSU05; DN 150mm; length 60mm; pressure range 0…8bar
ABS42
mounted pilot valve series ABS; suitable for pneumatically operated knife gate valves; 5/2-way solenoid valve; flow control valves; silencer; mounted at cylinder; standard coil C001; connector size 22mm; 5/2-Wege-Magnetventil (E52W1SM14); DN gate valve 50-400mm
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

Intrastat No.: 84818061
Country of origin: Spain
Weight: 20.96 Kg
Short Itemnumber: A1N2H25150PIBABS42C00103C002316
https://www.stasto.pl/web/image/product.template/233526/image_1920?unique=eb38ccc

A1N2H2-5-150-PIB
knife gate valve with double acting actuator series A1N-PIB; wafer type; body cast iron EN-GJL-250/ductile iron EN-GJS-500-7; gate AISI 304; soft sealed EPDM; packing PTFE-synthetic/EPDM; screws stainless steel; nominal flange pressure PN10; unidirectional sealed; control pressure 5,5...8bar; medium temperature -5...+90°C; prepared for 2 inductive switches MSU03, MSU04, MSU05; DN 150mm; length 60mm; pressure range 0…8bar
ABS42
mounted pilot valve series ABS; suitable for pneumatically operated knife gate valves; 5/2-way solenoid valve; flow control valves; silencer; mounted at cylinder; standard coil C001; connector size 22mm; 5/2-Wege-Magnetventil (E52W1SM14); DN gate valve 50-400mm
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

4.262,70 zł 4262.7 PLN 4.262,70 zł

cena na zapytanie

  • Connection
  • DN
  • Length
  • Cable length
  • Function
  • Actuation
  • Connector size
  • Design
  • Voltage
  • Pressure range
  • Switch design
  • Coil
  • Flow rate
  • Suitable silencer

This combination does not exist.
